Hengshui Hongwo Technology Co., Ltd., specialize in producing high-quality Fiberglass H-beam Profile products, focusing on delivering reliable and efficient solutions. Our advanced manufacturing techniques ensure each H-beam profile is precise and consistent. We use premium-grade materials to create beams that are lightweight yet extremely strong and durable, ideal for various applications from construction to industrial use.
Fiberglass H-beam Profile Specification:
To provide a more specific range of sizes for fiberglass H-beam profiles, let’s consider some common dimensions.
- Height and Width of the Beam (H and B): For the fiberglass H-beam, the height (H) and width (B) typically range from 100 mm (4 inches) to 600 mm (24 inches). The height refers to the vertical section, while the width pertains to the horizontal flanges. These dimensions, often similar, can vary, with standard sizes extending from smaller beams, like 100 mm x 100 mm, to larger ones up to 600 mm x 300 mm.
- Flange Thickness (T): The flange thickness (T) of the beam, which is the thickness of the horizontal sections at the top and bottom, typically ranges from 6 mm (0.24 inches) to 25 mm (1 inch).
- Web Thickness (t): The web thickness (t), pertaining to the beam’s central vertical section, is essential for its load-bearing capacity. This thickness generally ranges from 5 mm (0.2 inches) to 20 mm (0.8 inches).
- Length: The standard length of these beams varies, typically ranging from 3 meters (10 feet) to 12 meters (40 feet). However, they can be custom cut to specific lengths as needed to suit various application requirements.
- Weight per Meter: This is often specified for ease of handling and to calculate load during transportation and installation.
- Load Capacity: The maximum load the beam can handle, which depends on its size, shape, and the material’s properties.
- Material Specifications: Fiberglass beams can be made with different types of resins and fiber reinforcements, affecting their strength, thermal resistance, and other properties.
Remember, the choice of size will depend on the structural load requirements, environmental conditions, and installation considerations of your specific project.
| Size: Width A(mm)*Width B*(mm)*Height C (mm)*Thickness T (mm) | |||
| 25*25*15*4 | 30*20*10*4 | 33*33*20*4 | 38*38*15*4 |
| 40*25*15*4 | 50*25*15*4 | 58*58*15*4 | 65*25*25*3 |
| 70*70*25*4 | 100*100*80*5.5 | 110*110*50*6 | 150*150*150*7 |
Characteristics of FRP H Beams
Our FRP beams at Hengshui Hongwo Technology Co., Ltd. are known for their robust support capabilities, ideally suited for long-span and high-strength structures. They feature superior shear and bending capacity, are easy to fabricate, and boast an aesthetically pleasing design. These beams are not only corrosion-resistant, maintenance-free, and fire retardant, but also UV-resistant, offering excellent insulation and magnetic permeability. With their high bearing capacity, they are perfect for applications in bridges, roof bracing, and industrial platforms. The durability and corrosion resistance of our Fiberglass H-beam Profiles make them well-suited for challenging environments, while their non-conductive properties ensure safety in projects requiring electrical insulation.
Alias and Similar Names
These aliases and names are often used interchangeably to describe fiberglass-reinforced plastic (FRP) or glass-reinforced plastic (GRP) beams, each highlighting different aspects of their design and applications. These additional names and descriptions provide a broader understanding of the various terms used to describe FRP/GRP H-type beams and their characteristics in construction and industry.
- FRP/GRP H Beam: FRP/GRP H beams are reinforced with fiberglass and offer high strength-to-weight ratios, making them ideal for structural applications.
- FRP/GRP I Beam: Similar to H beams, FRP/GRP I beams are reinforced with fiberglass and are widely used in construction for their durability and lightweight properties.
- Pultruded Fiberglass FRP Beams: Pultruded fiberglass FRP beams are extruded using a pultrusion process, resulting in strong, corrosion-resistant beams suitable for various industries.
- Structural FRP I-Beam: Structural FRP I-beams provide structural integrity while being resistant to corrosion, making them valuable in harsh environments.
- Fiberglass H-Beam Profile: Fiberglass H-beam profiles are specifically shaped for load-bearing purposes, offering the benefits of fiberglass in structural design.
- Fiberglass Reinforced Plastic H-Beam: Fiberglass Reinforced Plastic H-beams are composite structural elements known for their corrosion resistance and high strength, making them a versatile choice in various industries.
- GRP H-Section Beam: GRP H-Section Beams, or Glass Reinforced Plastic H-section beams, are lightweight and durable structural components commonly used in construction and infrastructure projects.
- FRP H-Channel Beam: FRP H-Channel Beams, or Fiber-Reinforced Plastic H-channel beams, exhibit excellent load-bearing capacity and resistance to chemicals, making them valuable in corrosive environments.
- Fiberglass H-Profile Beam: Fiberglass H-Profile Beams feature a distinctive profile design, optimized for distributing loads efficiently while maintaining the benefits of fiberglass reinforcement.
- Composite H-Beam: Composite H-Beams refer to structural beams constructed from composite materials, offering a balance of strength, durability, and versatility for various applications.
Usage in Various Applications
The versatility of our FRP beams extends across a broad spectrum of structural needs. Due to their robust bearing capacity, they are extensively used in constructing bridges, supporting roof structures, and creating stable platforms in industrial settings. Their corrosion resistance makes them especially valuable in environments prone to chemical exposure or extreme weather conditions. This resistance, coupled with their non-conductive attributes, positions our FRP beams as an optimal solution for a wide array of industrial and construction applications, particularly where safety and durability are paramount.
Installation and Maintenance
Designed with practicality in mind, our Fiberglass H-beam Profiles facilitate ease of installation and maintenance. The lightweight nature of these beams simplifies handling, significantly reducing labor time and installation costs. This aspect is crucial for projects with stringent timeframes or budget constraints. Moreover, the minimal maintenance requirement of our beams ensures long-term cost-effectiveness and hassle-free operation. Hengshui Hongwo Technology Co., Ltd., commitment to innovation and quality is reflected in our continuous efforts to refine the installation process and enhance product performance, striving to exceed customer expectations in both quality and reliability.
